DÉTAILS
Léger. Rapide. Implacable.
A - head tube angle
72.5 °
B - head tube length
135.0 mm
C - top tube horizontal
550.0 mm
D - standover height
778.0 mm
E - BB offset
-70.0 mm
F - BB height
274.5 mm
G - Addict RC
992.0 mm
H - BB center to toptube center
480.0 mm
I - BB center to top of seattube
540.0 mm
J - seat angle
73.6 °
K - chainstay
410.0 mm
L - reach
390.0 mm
M - stack
548.0 mm
N - stem length
110.0 mm
O - centre saddle - centre bar (hor.)
694.0 mm
P - centre saddle - centre bar (vert.)
103.0 mm
Q - reach centre bar
485.0 mm
R - stack centre bar
607.0 mm

Cadre
Addict RC Disc HMX Road Race geometry / Replaceable Derailleur Hanger Internal cable routing
Fourche
Addict RC HMX Flatmount Disc 1 1/4"-1 1/2" Excentric Carbon steerer
Dérailleur arrière
SRAM RIVAL eTap AXS 24 Speed Electronic Shift System
Dérailleur avant
SRAM RIVAL eTap AXS Electronic Shift System
Manettes de dérailleur
SRAM RIVAL eTap AXS HRD Shift-Brake System
Pédalier
SRAM RIVAL Crankset 48/35 T
Boitier de pédalier
SRAM DUB PF ROAD 86.5
Chaîne
SRAM RIVAL
Cassette
SRAM RIVAL XG1250 10-30
Freins
SRAM RIVAL eTap AXS HRD Shift-Brake System
Disque de frein
SRAM Paceline rotor 160/F and 160/R
Cintre
Syncros Creston 2.0 Compact Alloy
Potence
Syncros RR 1.5 1 1/4"
Tige de selle
Syncros Duncan 1.0 D-Shape
Selle
Syncros Belcarra Regular 2.0
Jeu de direction
Syncros Addict RC Integrated
Paire de roues
Syncros RP2.0 Disc 28 Front / 28 Rear Syncros Axle / Removable Lever with Tool
Pneu avant
Schwalbe ONE Race-Guard Fold 700x28C
Pneu arrière
Schwalbe ONE Race-Guard Fold 700x28C
Poids en Kg
8.3
